Loading Multiple Tables With Azure Data Factory

There arn’t many articles out there that discuss Azure Data Factory design patterns. One big concern I’ve encountered with customers is that there appears to be a requirement to create multiple pipelines/activities for every table you need to copy. This conjures up images of massive, convoluted data factories that are a nightmare to manage.

Whilst the ForEach functionality has existed in ADF V2 for a while now, it’s recently been enhanced to enable mass copying of tables without having to specify a target Linked Services and datasets for each table.

In this simple post I’m going to show you how to get started with this new functionality.

Using the Copy Data tool (and the Pipeline Editor), you can specify your target data source, then select multiple source tables. When you specify the target data source, Data Factory generates a ForEach activity that in turn calls a Copy activity that’s parameterized for each source table.

To get started we need to have an Azure Data Factory created, along with a Source and Target. In this example, I’ve used the Azure SQL Database with the sample AdventureWorks database and Azure Blob Storage as my target. See the following for assistance in getting setup –

Create A Data Factory

Create An Azure SQL Database

Create An Azure Blob Storage Account

With that all done, we launch our newly created Data Factory from the Azure portal, and select the Copy Data wizard –




Copy Data

Which takes us to our Copy Data wizard. Fill in the the Task name and leave the rest as is.


Give The Pipeline A Name

Click Next, and click “Create New Connection” to create our Source Linked Service –

adfcopy3createnewconnection

Choose A Source Data Store

For this example, choose “Azure SQL Database” –

adfcopy4choosesqldb

Linked Services

With your Linked Service chosen, populate your source details (Server, Credentials etc) from the SQL Database you created earlier and click “Continue”. This takes you to the “Select Tables” screen, and select all the tables you wish to copy –

adfcopy6choosetables

Choose Tables For Extraction

Define your destination data store in the same way as you created the source data store. In this example I’m using Azure Blob Storage as part of an ELT (Extract, Load & Transform) pipeline, and is called “staging” in my example. It’s my storage account which will act as the landing/staging area for incoming data.

adfcopy7stroagetarget

Destination Data Store

In your Destination Linked Service, complete the necessary details as prompted. As I’m using Blob Storage I simply have to designate the path, which in this instance is my “raw” container within my landing area. If it was a database source this would ask for me to map source tables to target tables.

adfcopy8blobrawfolder

Output Destination (This Screen Will Vary Depending On Your Destination)

Finish the wizard and run the completed pipeline –adfcopy11finalscreen

Once completed, we can see in our blob storage landing area that all my files have been successfully copied.

adfcopy15storageview

So far, so amazing, right? The even better bit is when we go to view the Data Factory pipeline we created, and instead of seeing loads of Copy activities, we simply see one, innocuous ForEach activity –

adfcopy12inadfForEach

Just One Activity – What Witchcraft Is This?

Expanding “Activities” shows us there’s just been one “Copy” activity created, and is in fact parameterized with the relevant values (source table, target destination etc) being passed as a JSON array.



adfcopy16jsonarray

ForEach Activity Parameters

Which then instructs our Copy activity what to do –

adfcopy14CopyhActivity

Copy Activity Source



And we’re done. Much simpleness. For those of you have gone through the pain of creating endless packages in SSIS for simple copy/1:1 data flows, and have previously been creating similar amounts of Copy activities in Data Factory, hopefully this new release will make your ETL/ELT development a much simpler process.

Happy Factory-ing!











Building The Data Warehouse-less Data Warehouse (Part 2 of 2)

Part 1 of this series can be found here.

In my previous post I discussed and explored the feasibility of building a simplified reporting platform in Microsoft Azure that did away with the need for a relational data warehouse. In this article, I proposed that we land, process and present curated datasets (both dimensional files for our data warehouse “layer” and other data assets for our data scientists to work with) within Azure Data Lake Store, with the final step being to product a series of dimension and fact files to be consumed by our semantic layer. The diagram below highlights this approach:

conceptualmodeldwlessdw

At the end of the previous post I’d produced our data warehouse files (dimensions and facts) and in this second and final part I will show how we consume these files with our semantic layer (Azure Analysis Services) to finally present a business-friendly reporting layer without a data warehouse in size.

Semantic Layer

A semantic layer presents the business view of the data model, and allows users to interact with the layer without needing knowledge of the underlying schema or even knowledge of writing SQL code. In the words of my colleague Christian Wade, it’s “clicky-clicky draggy droppy” reporting that provides a single version of the truth without risk of users creating inaccurate measures by a misplaced join or incorrect Group By statement.

Microsoft’s semantic layer offering is Azure Analysis Services, and allows users to connect to models built with Analysis Services using any compliant tool, such as Power BI and Tableau.

I create an Azure Analysis Services project in Visual Studio, and connect to my Azure Data Lake Store from Part 1 (Ensure you change your model to use the latest SQL Server 2017/Azure Analysis Services Compatibility Level) :

aasdatalakestore

Azure Analysis Services Get Data

In the Query Editor I create queries that pull in the csv files that I created earlier for DimProduct, DimCustomer and FactSales:

aasimport

Query Editor

Note, whilst it’s relatively straight forward to import csv files into Azure Analysis Services from Data Lake Store, my colleague Kay Unkroth wrote a great article that makes this much easier, and I use this method in my solution. Please see this article for further details.

Once the tables have been imported into Azure Analysis Services, it’s then a simple feat to define our star schema and create a couple of measures:

simpleschema

Simple Star Schema (No Date Dimension Yet!)

We then publish our Analysis Services model to the Azure Analysis Services Server we created in part 1, and connect to it using Power BI:

powerbiexample

Power BI Example

That’s it, all done!

Not quite…

Refresh and Orchestration

So we’ve shown now that you can ingest, process and serve data as dimensional constructs using Databricks, Data Lake Store and Analysis Services. However this isn’t at all useful if the pattern can’t be repeated on a schedule. From Part 1, we use Azure Data Factory to copy data from our sources and also to call our Databricks notebook that does the bulk of the processing. With our Analysis Services model now published, we simply need to extend our Data Factory pipeline to automate processing the model.

Logic Apps

There are a few methods out there for refreshing an Azure Analysis Services cube, including this one here. However I particularly like the use of Azure Logic Apps for a code-lite approach to orchestration. Using Logic Apps I can call the Azure Analysis Services API on demand to process the model (refresh with latest data from our data store). The Logic App presents a URI that I can then call a POST against that triggers the processing.

Jorg Klein did an excellent post on this subject here, and it’s his method I use in the following example:

logicapps

Logic App Example

Once you’ve verified that the Logic App can call the Azure Analysis Services refresh API successfully, you simply need to embed it into the Data Factory workflow. This is simply a matter of using the Data Factory “Web” activity that is used to call the URI obtained from the Logic App you created above:

logicappPost

Logic App Post URL

Our final (simplified for this blog post) Data Factory looks like this, with the Web Activity highlighted.

datafactorywithweb

A simple test of the Data Factory pipeline verifies that all is working.

Conclusion

So, there you have it. My aim in this post was to see if we could create a simplified data warehouse-like approach that did away with a relational data warehouse platform yet still provided the ability to serve the various workloads of a modern data platform. By keeping the data all in one location (our data lake), we minimize the amount of data movement, thus simplifying many aspects, including governance and architecture complexity.

In terms of how we did it:

  1. Ingested data from source systems using Azure Data Factory, landing these as CSV files in Azure Data Lake Store
  2. Azure Databricks was then used to process the data and create our dimensional model, writing back the data files into Azure Data Lake Store
  3. Azure Analysis Services ingested the the dimensional files into its in-memory engine, presenting a user friendly view that can be consumed by BI tools
  4. Refresh of the Analysis Services model was achieved using Azure Logic Apps, with this component being added to our data pipeline in Azure Data Factory

Is This A Viable Approach?

Simply put, I believe the approach can work, however I think it is definitely dependent on specific scenarios. You can’t, or at least, not very easily, create “traditional” data warehouse elements such as Slowly Changing Dimensions in this approach. The example proposed in these articles is a simple star schema model, with a “rebuilt-every-load” approach being taken as our data sets are very small. For large, enterprise scale data warehouse solutions you need to work in different ways with Data Lake Store than we would do with a traditional data warehouse pipeline. There are many other factors to discuss that would affect your decision but these are out of scope for this particular article.

So, can we build a datawarehouse-less data warehouse?

Yes we can.

Should we build them this way?

It depends, and it’s definitely not for everyone. But the joy of cloud is you can try things out quickly and see if they work. If they don’t, tear it down and build it a different way. One definite benefit of this particular solution is that it allows you to get started quickly for an alpha or POC. Sure you might need a proper RDBMS data warehouse further down the line, but to keep things simple get the solution up and running using an approach such as suggested in this article and “back fill” in with a more robust pipeline once you’ve got your transformation code nailed down.

Happy building.

Further Reading

Azure Analysis Services With Azure Data Lake Store

Process Azure Analysis Services Using Logic Apps

Operationalize Databricks Notebooks Using Azure Data Factory

Building The Data Warehouse-less Data Warehouse (Part 1 of 2)

*Update – part 2 of this series is now live, and can be found here*

In times of yore, those who maketh the houses of data would bring forth vast swathes of tables and hurl them down in the forts of staging. Here the ancient priests of Ee, Tee and El would perform arcane magicks and transform these rows of chaos into purest order. This order would be rebuilt into the fabled Data Warehouses, and all who looked upon them would gasp in awe and wonder.

But that was then. Today’s data world is different, isn’t it? Data is varied. It’s big and small, fast and slow. It’s tougher to wrangle and make into shapes fit for use. But through all of this, we still need the hallowed, fabled, data warehouse.

Or do we?

This post is basically me exploring a different approach to building a data warehouse that’s based on the data lake paradigm and a form of ELT (Extract, Transform and Load), but leaves out the actual data warehouse part. I’m still going to build a star schema, but it’s going to be file based, using modern data engineering tools to do the munging and “schema-tizing” before sucking into a semantic layer for reporting. It’s also me exploring the capabilities of my current favourite tool – Azure Databricks.

What are the potential benefits of this approach? A few spring to mind, such as cost, flexibility and simplicity. By keeping all the processing within the data lake means it’s easier to control and govern, and the reduced data movement (you’re not copying into a data warehouse) makes an altogether more simpler structure.

Conversely, I’m well aware that this approach brings it’s own challenges. Traditional data warehouse constructs like Slowly Changing Dimensions, Surrogate Keys and other elements of the Kimball checklist will be harder or even not possible with this, so it won’t suit every scenario.

My aim here though was simple – can we build a BI solution without the data warehouse element and is it a viable approach for certain scenarios?

In short, the solution looks like this:

conceptualmodeldwlessdw

File-based Data Warehouse Conceptual Model

The above construct largely follows the traditional ETL model with data flowing in from source systems, and comprises the following:

  1. Data ingested as raw files into a staging zone in the data lake
  2. Files processed using data engineering platform into cleansed outputs
  3. Scrubbed files then shaped and moved into relevant serving zones. In this example I’ve kept it simple, with one zone for the star schema files and one for a data assets folder that provides cleansed, curated data sets to be consumed by analysts and data scientists.
  4. The star schema files are subsequently loaded into a semantic layer for enterprise reporting and ad hoc slice n’ dice functionality, whilst the asset files are consumed using the variety of tools preferred by today’s analysts.

To bring this to life, I’ll be using a handful of Azure data services for the relevant solution components –

solutioncomps

Solution Components

In this example, I’ll be using an Azure SQL Database as my data source with the AdventureworksLT database.

Prerequisites

For each of the above, ensure you put everything in the same Azure region.

Extract

There are plenty of options in this space that could move data from source to my lake, including ETL tools such as SSIS, Talend and Azure Data Factory. For this example I’m using Azure Data Factory (version 2), with copy activities moving data from my source SQL database and dropping as *.csv files. I’m also taking advantage of the new Databricks functionality built into Azure Data Factory that allows me to call a Databricks Notebook as part of the data pipeline.

datafactory

Data Factory Copy Activity

The above data factory copies the source tables into my “raw” directory, and from there I process the files, with the end result being to create my dimension and fact files ready to be loaded into Azure Analysis Services.

files

Load Files Into Spark DataFrames

With this files safely copied into our raw landing zone, I can now extract the source tables directly into Spark DataFrames. An example is shown below for the product table. We create a DataFrame for each source file.

dataframesrpoduct

Example DataFrame Creation

Transform

With the DataFrames created, I then create temporary SQL tables from them so that we can use SQL code to define my dimension. You can of course manipulate them natively as DataFrames using Python/Scala/R if you’re more familiar with those languages. I’m a SQL dude, and am familiar in building data warehouse routines in SQL code so have opted for that method here.

createview

Create Temporary Views From DataFrames

With these views created we can use good ‘old SQL to create DataFrames that reflect the dimensions and facts we want to load into Azure Analysis Services.

exampledim

Dimension Example

and fact tables:

examplefact

Fact Example

When I run my notebook now I have my dimensional and fact tables created as Spark dataframes. In order for them to be consumed by Azure Analysis Services I need to write the dataframes into CSV files that can then be imported into my tabular model.

Output Dimension and Fact Files

Writing files back from Spark into csv wasn’t as seamless as I thought it would be. Whilst the commands are fairly straight forward, as Spark is a distributed system it writes multiple files as an output, including crc and SUCCESS metadata files. It also doesn’t name them as the file you specify, but instead names it based on the partition name.

We don’t need these files, and need a proper, consistent filename, so I wrote some extra code to rename and move the files back under our Data Warehouse directory.

writetofile

Writing Out To CSV

With all this done, it leaves us nicely with a set of files ready for ingestion into Azure Analysis Services, which is the subject of Part 2 of this series.

outputfiles

Outputted Dimension And Fact Files

Coming in the second and final part of this series…

  • Build an Azure Analysis Services model directly off the dimension and fact files within the Data Lake Store
  • String it all together using Azure Data Factory

Part 2 is now live, and can be found here….

Incremental ETL Processing With Azure Data Factory v2

Data Factory V2 was announced at Ignite 2017 and brought with it a host of new capabilities:

  • Lift your SSIS workloads into Data Factory and run using the new Integrated Runtime (IR)
  • Ability to schedule  Data Factory using wall-clock timers or on-demand via event generation
  • Introducing the first proper separation of Control Flow and Data Flow to allow more complex orchestrations such as looping,  branching and other conditional flows
  • Incremental Loads using the new Lookup Activity

And it’s this last item that today’s article is about.

It’s fair to say that in its initial incarnation, Data Factory didn’t allow for more traditional ETL workloads without some complex coding (more than you were used to if you came from the world of SSIS and similar ETL tools). For the big data focused ELT workloads where data is moved between data services (SQL Server, Blob Storage, HDInsight and so forth) and activities applied whilst the data is in place (SQL queries, Hive, USQL, Spark) Data Factory V1 really excelled, but for those who wanted to move their traditional ETL delta extracts to Data Factory, it wasn’t quite there.

In this new public preview the product team have taken great steps in remedying this, allowing ETL developers to implement proper incremental loading patterns with their relational data warehouses.  It’s also worth knowing I’ve seen where Data Factory is going, and it’s looking amazing…

The following example is based on the official tutorial here. The differences in this example are based on the scenario where you wish to perform incremental extracts from a source database to a staging area inside another database. This example uses Azure SQL Database as both the source and sink, but can be adapted for other data sources.

The solution files used in this example can be found here

Prerequisites

This example assumes you have previous experience with Data Factory, and doesn’t spend time explaining core concepts. For an overview of Data Factory concepts, please see here.

So for today, we need the following prerequisites:

  • An Azure Subscription
  • An Azure SQL Database instance setup using the AdventureWorksLT sample database

That’s it!

Incremental Loading in Data Factory v2

The diagram demonstrates a high level overview of the process, and should be familiar to those who have built similar data flows with other ETL tools such as SSIS:

advv2incloadingoverview

Incremental Loading Overview

Process

There are four main steps to this process to create an end to end incremental extract.

  1. Identify the trigger column. In the Data Factory documentation this is referred to as the Watermark column so I’ll use this latter term for consistency going forwards. This column is one that can be used to filter new or updated records for each run. This column is normally an automatically updating datetime column (e.g. Modified_Date_Time) or an ever increasing integer. We use the maximum value of this column as the watermark.
  2. Create a data store to hold the watermark value. In this example we store the watermark value in our SQL Database.
  3. Create a pipeline that does the following:
    • Creates two Lookup Activities. The first looks up the last watermark value and the second retrieves the current watermark value.
    • Create a Copy activity copies rows from the source where any watermark values are greater than the old watermark value. These delta rows are then written to our target table.
  4. Create a stored procedure that updates the watermark value, ready for the next run.

Building the Solution

Create a Staging Table

In this example, we’ll use the SalesOrderDetail table in the AdventureWorksLT database:

salesorderdetail

SalesOrderDetail

And we will use the ModifiedDate as the watermark column.

We therefore need to create a target or “staging” table to load our delta rows into.

Run the following SQL in your created database to create a staging version of the SalesOrderDetails table:

CREATE TABLE [SalesLT].[SalesOrderDetail_Staging]

(

[SalesOrderID] [int] NOT NULL,

[SalesOrderDetailID] [int] NOT NULL,

[OrderQty] [smallint] NOT NULL,

[ProductID] [int] NOT NULL, [UnitPrice] [money] NOT NULL,

[UnitPriceDiscount] [money] NOT NULL,

[LineTotal] [money] NULL,

[rowguid] [uniqueidentifier] NOT NULL,

[ModifiedDate] [datetime] NOT NULL,

[ExtractDate] [datetime] Default Getdate()

)

Create a table for our watermark values

Run the following command in your SQL Database to create a table named watermark that will store our watermark value:

create table watermark
(

TableName varchar(255),
WatermarkValue datetime,
);

Set the default value of the watermark with the name of our source table. In this example, the table name SalesOrderDetail.

Insert into watermarktable
values (‘SalesLT.SalesOrderDetail’, ‘1-jan-2017’)

Create a stored procedure in our SQL Database:

This stored procedure is used to update the watermark table when new rows have been extracted.

CREATE PROCEDURE sp_write_watermark @LastModifiedtime datetime, @TableName varchar(50)
AS

BEGIN

UPDATE watermarktable
SET [WatermarkValue] = @LastModifiedtime
WHERE [TableName] = @TableName

END

Create Some Trigger Data

Run the following command on your SQL database to update a couple of rows in the source table. This is to validate the process is working correctly as it marks the rows as modified with today’s date, which is greater than the row in our watermark table. If the process is successful it will extract these changed rows.

update [SalesLT].[SalesOrderDetail]
set modifieddate = getdate()
where salesorderid = 71774

Create a Data Factory

Create a new Data Factory. For ease, do it via the portal following this guide.

(Ensure you create it using ADFv2):

adfv2

Creating a Data Factory via the Azure Portal

Create your Data Factory Artifacts

You will need to create the following (I’ve included my own samples in the link at the beginning of this article):

  • AzureSQLLinkedService
  • A source SQL dataset (for our source table)
  • A target SQL dataset (for our destination table)
  • A watermark dataset (that stores our watermark value entries
  • A pipeline that coordinates the activities

Modify the files to suit your needs and setup for your database server and database.

I won’t show the different JSON here, but just to highlight, the key area is the new Lookup Activity shown below:

pipelinelookupactivity



Create a folder on your root C Drive to hold the created JSON files

I created a folder called “adf” and put all my JSON files there:

adffolder

Deploy Data Factory Artifacts

For the current preview, you cannot deploy using the GUI, so you need to deploy programmatically. For this example I’m using Powershell. Note you will need to update your Powershell install with the latest cmdlets by running the following command:

Install-Module AzureRM

After updating the AzureRM cmdlets, run the following Powershell script below (attached at the start). This will deploy the necessary artifacts to your Data Factory.

powershellex2

Run the pipeline

Once deployed, you can run the deployed pipeline via Powershell with the following command:

$dataFactoryName = “[Your DATA FACTORY NAME]”
$resourceGroupName = “[Your RESOURCE GROUP NAME]”

$RunId = Invoke-AzureRmDataFactoryV2Pipeline -PipelineName “mainPipeline” -ResourceGroup $resourceGroupName -dataFactoryName $dataFactoryName

This fires off the pipeline. You can monitor its progress using Monitor & Manage:

minotoradf

Monitor Data Factory

And this allows you to see the status of the running pipelines:

pipelineruns

With the pipeline processed successfully,  I’ll check my database tables to check everything has updated correctly:

stagingdemo

Delta Rows Extracted

Bingo!

And the watermark table has been updated successfully:

watermarkupdate

Updated Watermark Table

This completes this article covering a simple ETL incremental extraction using the new Data Factory. The roadmap for this product is very exciting, and I encourage you to check out the links below for further reading:

Introduction to Data Factory v2

Data Factory Ignite 2017
